Description
Product Features
- Multi-Constellation Signal Support: Compatible with GPS L1/L2 BeiDou B1/B2 GLONASS G1 and Galileo E1/E5 signals; multi-feedpoint technology enhances precision in urban canyons forests mountainous areas for automotive drone outdoor tracking needs
- High-Gain Low-Noise Performance: Dual-stage LNA amplification (28 dB high gain) with ≤2 dB noise coefficient; 2-path filtering minimizes interference ensuring stable signal reception even at low elevation angles
- IP65 Waterproof Durable Design: ABS+PC composite shell (115x71.8x30mm) resists cracking corrosion; withstands extreme temperatures (-40°C to +85°C) and 95% humidity ideal for outdoor industrial use
- Wide Voltage Easy Installation: Operates on 2.8 V - 12 V DC with low power consumption (≤65mA); TNC female connector with screw mounting ensures secure attachment to vehicles drones IoT devices
- Certified Long-Lasting Reliability: TS16949-certified manufacturing process; passes 24-hour high/low-temperature tests (-40°C~+85°C); built-in ESD protection ensures extended durability in harsh environments
-
Specification:
Working Frequency: 1176MHz/1207MHz /1227MHz/1575MHz /1561MHz/1602MHz
Channel: L1/ E1 /B1C /G1 /B1 /L2 /E5B
B2(I/Q) /B2b /B2a /L5 /E5 /E5a
Impedance:50ohm
Polarization:right-handed circular polarization
LNA Gain:28dB
Vswr:≤ 2.0
Noise figure: ≤2dB
Operating voltage: +2.8V~3.3VDC
Operating current: ≤30mA
Filter :2-way filtering
Connector:SMA Male
Weight:
RoHS/REACH compliant
Operating Temperature：-35℃ ～ +80℃
Storage Temperature：-40℃ ～ +85℃
Package Content: 1 x Antenna
Applications:
Automotive telematics and fleet management
Marine navigation systems
Outdoor IoT asset tracking
UAV/drone positioning
