Specifications:
Frequency range: FM 87.5-108MHz, DAB 170-230 1452-1492MHz
Strap width: 100 MHz
Impedance: 75 ohms
VSWR<2 Gain: 3dBi
Polarisation: Vertical polarization
Telescopic antenna length: 15.5 cm (6.1 inches) - 75.5 cm (29.7 inches)
Base height: 3 cm
Base diameter: 4.8 cm
Cable length: 3 m (10 feet)
Antenna interface: F-type connector
Net weight: 122 g
Operating temperature: -20 °C ~ +80 °C
Storage temperature: -30° to +85°
Note:
Check which channels are available in your region before purchasing this antenna.
The effectiveness of the antenna is affected by the distance from the signal jump point, the signal strength of the station, antenna positioning, reflections from nearby structures and any power consumption sources.
The amount and quality of the transmitters you receive depends on the position of the transmitter masts, the signals emitted and the strength of the transmission signals in your area. Install the antenna as high as possible and near a window for better reception. Do not place or hide the antenna in/behind metallic objects.
Keep the antenna away from devices with high power consumption to avoid interference.
