Bingfu Shark Fin Antenna for Car/Truck/RV - FM/AM Radio + GPS/BeiDou Dual-System, 28dB High Gain LNA, IP65 Waterproof, 9-16V Wide Voltage

BingfuSKU: BFUSAN0534

Price:
Sale price$43.49

Description

Product Features

  • Dual Radio & Precision Navigation: FM 87.5-108MHz and AM 522-1710KHz for radio enjoyment; Integrated GPS and BeiDou satellite reception delivers reliable navigation for cars trucks and RVs
  • Enhanced Signal Reception: High gain 28 dB amplifier with low noise design minimizes interference; Boosts weak GPS radio signals even in challenging city or remote rural areas
  • Weatherproof Construction:IP65 waterproof housing protects against rain snow and dust; Durable materials withstand extreme heat or cold from -40° C to +85° C
  • Universal Power & Easy Fit: 9-16V wide voltage compatibility works with most vehicles; Simple secure shark fin design mounts easily onto car truck or RV roofs
  • Stable Reliable Performance:Secure installation resists road vibration bumps and shocks; Ensures continuous signal for radio stations and GPS tracking during long drives





Specifications

Feature Multi-Functional Shark Fin Antenna for Automotive Navigation & Entertainment. The A-FM/AM+GNSS antenna combines FM/AM radio reception with high-precision GNSS positioning, designed for seamless integration into vehicles, RVs, and commercial trucks.
Environmental Resilience RoHS/REACH compliant
Operating Temperature -40°C to +85°C
Storage Temperature -40°C to +90°C
Humidity 0% to 95% (non-condensing)
Applications Automotive FM/AM radio reception, Fleet vehicle tracking and navigation, RV and truck GPS systems, Off-road adventure equipment


FM/AM Radio Module :
Frequency Range FM: 87.5-108MHz, AM: 522-1710KHz
Gain FM: 17-23±2dB, AM: 0-5±2dB
VSWR ≤3.0
Impedance 50±5Ω
GNSS Module:
Supported Signals GPS L1: 1575.42±2.5MHz ; BeiDou B1: 1561±2.5MHz
Bandwidth >10MHz
Gain 3.0Bi (70x70mm patch)
VSWR ≤2.0
Polarization Right-Hand Circular (RHCP)
LNA Specifications:
Gain 28±2dB
Noise Figure ≤2.0dB
Operating Voltage 3.0-3.6V DC
Current Consumption 8±3mA
